Flying shark vertical takeoff and landing fixed-wing VTOL vertical takeoff and landing aircraft mapping drone (spot)
Flying shark full composite VTOL vertical takeoff and landing electric mapping aerial survey drone (spot)
This machine is designed for dual motors. The whole machine is made of high-strength composite material with high strength and long service life. This machine has a large space, heavy load, and long battery life. It has a separate cabin for easy independent inspection. It adopts a quick-release structure, which is convenient to carry and assemble and takes off in 5 minutes in the field. Strong wind resistance, able to fly normally in the maximum 6-level headwind. It can be operated by one person and fully autonomously take off and land. After testing, a load of a SONY A7R2 camera, the speed of the cruise is 78 km / h, the actual flight is about 180 minutes. The aircraft adopts an advanced aerodynamic layout to ensure the aircraft’s excellent stability and economy, which is very suitable for surveying, monitoring, and patrol long-term use.
The biggest advantage of this machine: only one set of batteries can be used to survey and fly over 160 kilometers of flight, and the operation and maintenance cost is low. There is a large enough equipment compartment, which can hold up to 2 A7R2 cameras for tilt photography, or a tilt camera with a small 5 lens for tilt photography, high flight stability, and the pitch and roll fluctuations in the wind are generally less than 3 degrees, greatly improving Aerial survey accuracy and success rate.
Can be customized according to customer needs, contact us for more information, Welcome to our actual inspection.
With the function of anti-light rain, the notebook ground station realizes one-button automatic take-off and landing. It has a complete automatic protection mechanism and multiple emergency backup points, 8 planned route settings, and the ground station has a separate mapping route and patrol route planning function.
The full installation and debug version includes:
1. Full composite aircraft including arm and motor mount (installed)*1
2. Customized front pull brushless motor *2
3. UAV special steering gear *4
4. Customized special hanging brushless power motor *4
5. Brushless ESC*6
6. Special carbon fiber paddle × 4
7. Special front pull paddle × 2
8.P900 digital radio station ×1
10. Industrial grade flight control × 1
