Description
The UVS-0C400 multi-function water robot is a water robot platform that independently implements multi-task systems for large waters such as offshore, harbor, lakes and rivers. It can be equipped with front-view sonar, single-beam/multi-beam sonar, side-scan sonar, shallow stratum. Profiler, HD camera, ADCP, water quality online analytical instrument, water sampler, sediment sampler, underwater camera, micro-dive submersible, underwater 3D laser scanner, etc., to achieve environmental monitoring, hydrological measurement, Geomorphology mapping, island reef supply, emergency rescue, security patrol, nuclear radiation monitoring, maritime anti-smuggling and military anti-submarine and other tasks, can be widely used in security, military, surveying, maritime, fishery, offshore oil, meteorology, water, environmental protection, Nuclear power and other fields.
Performance characteristics
Equipped with equipment
Attack system, sound waves actively reject equipment, remote control machine guns;
Reconnaissance equipment Marine night vision equipment, miniature submersibles, anti-submarine equipment.
Sensing equipment side scan sonar, multi-beam sounder;
Application field
Surface combat/military exercises: enabling remote reconnaissance, search and rescue, demining, anti-submarine, etc.
Move, support group control, complete the tactics of the water group wolves.
Maritime patrol law enforcement / maritime supervision: can assist law enforcement personnel to achieve security
Patrol, coastal surveillance, transport escort, smuggling interception and other activities.
Maritime hydrological data collection: equipped with professional underwater mapping equipment and GNSS high
Precision positioning system, automatic mapping, convenient and efficient.
Technical specs:
Size: 3600 × 1600 × 890 (mm)
Payload / dead weight: 100kg / 280kg
Power System: Electric Propulsion
Ship type: double M multi-hull
Maximum speed: 8 knots
Economic speed: 6 knots
Life time: ≤ 3 hours
Anti-wind wave level: Level 3 sea state
