DJI M30 /M30T drone parachute, for DJI Matrice 30 drone’s emergency recovery, ensure the safety flight, based on DJI SDK, in-depth customization of APS parachute opening system, the parachute and drone two-way data exchange, The UAV sensor data and parachute sensor data are fused to sense the UAV’s flight attitude. The APS algorithm deploys the UAV to stop the propeller and open the parachute at the moment of danger to save the aircraft safely.
Sensor redundancy, only for safety, OWL DJI M30 drone parachute sensor adopts a redundant design to deal with various accidents. When one set of sensors fails, the other set of sensors can be seamlessly connected at the same time to supplement data and accurately identify drones. Flight status, troubleshoot parachute failures and ensure drone flight safety.
Quick-release design, quick installation, and disassembly, the 0WL-M30 parachute is designed for convenient installation, which does not affect the folding and use of the UAV, and can be used quickly on the field.
APS automatically opens the parachute. In order to improve the reliability of the Matrices 30 OWL parachute, we constantly test and simulate various complex accident situations, and debug the APS algorithm. When the UAV has an accident, the APS automatic parachute opening procedure will strictly abide by the stop propeller instruction- Open parachute command-start siren command-safety steps for slow descent to protect the safety of drones and ground personnel and property.
It can be reused. owl M30 adopts a modular design. The main control and parachute bag are divided into two. After deploying the parachute, there is no need to return to the factory to repair and fill . The pilot can buy the replacement parachute bag and install it by itself, which greatly reduces the operation time.
Specs:
Size | 130*105*45 mm |
Weight | 280g |
Parachute Cloth Size | 2.25㎡ |
compatible drone | DJI Matrice 30 |
Reaction time | 500ms-600ms |
Minimum parachute opening height | 23M |
Speed of decent | 4.6m/s |
Max load capacity | 4.5Kg |
Wind resistance rating | ≤level 7 |
Working altitude | ≤3500M |
IP Protection | IP45 |
Working temperature | -20℃ to 60℃ |
