The DJI M300 drone Air payload drop release hook mechanism system, develop on DJI onboard SDK, control the drop & release via DJI smart controller -the DJI Pilot, 5 hooks design, one time can mount max 5 different payloads, come with the quick-release design, easy to install.
- The DJI M300 air drop release Mechanism develops on DJI onboard SDK, compatible with DJI matrice 300 RTK drone.
- Control and operate the drop & release via DJI smart controller – the DJI pilot (not work with the latest DJI Pilot 2)
- 5 hooks design, one time can mount 5 payloads.
- Max payload weight more than 10Kg ( consider the DJI M300 drone payload capacity, suggest no more than 3Kg)
- Quick-release design, easy to install.
- The drop mechanism is made of aviation aluminum and carbon fiber, lightweight, heavy load.
- The NON -DJI SDK version is available, that works with any multi-rotor drone, controlled via PWM.
DJI M300 drop mechanism specs;
|Interface||DJI onboard SDK|
|Control distance||AS fas as DJI M300 drone flight|
|Max payload weight||10Kg (consider DJI M300 payload capacity,suggest no more than 3Kg|
|Other NON-DJI drone support||YES|
