CUBE Orange PIXHAWK2 PX4 Autopilot Flight Controller for Fix wing , Multi-rotors drones.
– Modular design for flexibility
– Ready for RTK GPS & multiple GPS
– Triple redundancy IMU system
– Isolated, dampened and temperature-controlled IMU
Key Design Points:
– Built-in IMU heating system, allowing flights at extreme temperature (below ice point)
– Robust DF17 interface connectors, enhance drop and shock resistance
– Airframes: VTOL, Plane, Multicopter 3-8Axis, Traditional Helicopter, Rover, Boat, Sub, General Robotics
Hardware Parameters:
– Main Processor: STM32F427 V3
– Companion Processor: STM32F1
– Supported Remote Control Signals: PPM/SBUS/DSM
– Power Redundancy: Support for 3-Way Redundancy
– Sensor Quantity:
L3GD20 (3-Axis Accelerometer)
LS303D (Accelerometer + Magnetometer)
MPU9250 x 2 (Accelerometer + Gyroscope + Magnetometer)
MS5611 x 2 (Barometer)
– Software: Supports for PX4 & Ardupilot Open Source Flight Control Software
Basic Parameters:
– Weight: 73g
– Materials: CNC Aluminum Alloy (Cube) + Molding ABS (Carrier Board)
– Operating Temperature: -10℃ to 55℃ IMU Constant Temperature Control
– PWM Output IO: 14
– Mavlink Serial Ports: 2
– Supported GPS: 2pcs
– Debugging Port: 1
– I2C Ports: 2
– CAN Port: 1
Flight Functions:
– Support position holding, fixed height flight, auto flight mode, following mode and other flight modes
– The ground station supports for Qgroundcontrol and Mission Planner
– Built-in flight data recording
– Real-time flight data transmission
– Support 360° obstacle avoidance (Extra distance sensor is needed)
Expansion Functions:
– Support for TX1, Raspberry Pi, Intel Edison, and other synergetic computers
– Support OSD display
Protection Functions:
– Smart return
– Low voltage protection
– Obstacle avoidance
– Remote control protection when it is beyond link
