The tethered system Air power module is installed on the drone end, converting high voltage to low voltage for drone work, it is a spare part of the M300 tethered system.
The DJI M300 drone tethered system onboard power converter, is a DC module power supply, 350-450Vdc input, output power 2000W,
The typical efficiency of the module: is 94.0%, the outer structure is a fully sealed aluminum substrate with a shell, and the power density is high. With input over-voltage protection, under-voltage protection, output over-voltage protection, output short-circuit protection, over-temperature protection; output over-current and short-circuit protection,It is a safe and efficient airborne power module for DJI M300 drone tethered system.
|Installation method||Quick -Release|
|Rated output current||50V|
|Rated input voltage||DC300-450V|
|Continuous flight time||24H (powerline Tethered )|
|Protection function||Over-voltage protection,
over current protection,
short circuit protection,
