Description
The DJI Matrice 4T dual-hook air payload drop release mechanism system is designed for the Matrice 4 series drones. Developed based on the DJI PSDK, it seamlessly integrates with the Pilot2 software for control. Equipped with a high-performance digital servo motor, each channel can drive a hook release with a maximum payload of 2 kg. The system is designed to minimize size without requiring any modifications to the drone structure. An external manual hook button allows for real-time manual loading. It also features a built-in warning light with five color combinations that flash alternately or synchronously. Compact and lightweight, this device is ideal for cargo delivery, emergency rescue, and various other operational scenarios.
Feature:
- DJI SDK payload drop system, control the drop via DJI Pilot.
- Dual drop hooks, each time can carry 2 payload, max load weight 2Kg
- Independent channel control drop kits, choose any drop hooks
Specs:
| Specification | Details |
|---|---|
| Dimensions | 56.5mm × 39mm × 26mm |
| Weight | 50g |
| Interface Type | TYPE-C |
| Control Method | DJI Pilot 2 |
| System Power | ≤ 3W |
| Operating Temperature | -20℃ to 60℃ |
| Number of Release Hooks | 2 |
| Control Range | as far as drone can fly |
| Installation Method | Non-destructive quick installation |
| Maximum Payload load weight | 2Kg (should consider the DJI M4T’s max payload capacity) |
| Warning Light | Red & blue strobe, five color combinations |
| Status Feedback | Real-time feedback of each drop channel status |
| Compatible Models | DJI M4T / M4E |
